Sima Double Roller Blinds Plain/Linen

Provide privacy and regulate light as well as present lithe and natural lighting effect to make the space stylish and fun

More made to measure Double Roller Blinds/Zebra Blinds

Insert sizes for an estimate: NTD {$ formatPrice(pre_calc_price) $} up

Width

cm

Out of range

Height

cm

Out of range

Customizable size range:
Width: {$ size_range.width.min ? size_range.width.min : '' $} {$ size_range.width.min && size_range.width.max ? ' ~ ' : '' $} {$ size_range.width.max ? size_range.width.max : '' $} cm {$ size_range.width.max ? '' : 'Above' $} |Height: {$ size_range.height.min ? size_range.height.min : '' $} {$ size_range.height.min && size_range.height.max ? ' ~ ' : '' $} {$ size_range.height.max ? size_range.height.max : '' $} cm {$ size_range.height.max ? '' : 'Above' $}

Specs

Specs

Measurement

Measurement

Installation

Installation

Case Portfolio

Case Portfolio

Specs& systems: Double Roller Blind-Sima

Basic Specs


[Size] includes headrail hardware
Ready-made: Can be customized within 150cm(W) x 180cm(H)
Custom-made: Can be customized within 250cm(W) x180cm (H)
Band height 7.5cm/Gap 5cm
[Material] Polyester, Aluminum Alloy
[Cleaning]  Non-washable on the surface, use a dry cloth, duster or a vacuum cleaner with a brush head to dust.

■ Complete installation instructions and components attached



Sizes& Figures


Ready-made Products

Simple Type(Unhidden roll with light bottom rail)




Custom-made Products

Delicate Type(Metalic upper cover bundle, and fix bottom rail by increasing weight)



 Brackets and hardwares are included in the blind. The total thickness after installation, depending on the system sizes and directions of installation, is about 5cm~10cm.
 S-type headrail system is applied in custom-made products with width below 180cm; M-type is applied with width above 180cm.
 If the blind is installed in the curtain box or notch, the inner depth should be at least more than 8cm~12cm for smooth installation.
 The covering area indents due to parts from left and right sides. Ballchain control: 2cm/ Bottom: 1.5cm.


Choosing Operation


Ready-made Products

Ballchain Loop(Safety guide attached)



Custom-made Products

1. Ballchain Loop(Safety guide attached)


2. Motorized remote control


3. Motorized simple pull
  No remote control, use pull only (Max W. 180cm) >> Demo Video



Color-matching Services


Ready-made Products

With white bracket, white plastic ballchain.

Custom-made Products
Bracket, headrail systems, and plastic ballchain- Four colors available: White/ Beige/ Grey( Metallic silver)/ Black.
Metal ballchian is available for purchase to create your own unique personality and brilliance.


Additional Purchase Service

Ready-made Products
 Tassel for ballchain-With ballchain loop. Design in Europe. Decorative tassel.

Custom-made Products
 Metal Ballchain-Grey Nickle/Black Nickle/Satin Nickle/Old Brass/Copper, Iron nickle plated
 Tassel-With ballchain loop. Design in Europe. Decorative tassel.
 Motorized remote control-Simple type only. Minimum width: 75cm

Operation/Cleaning

Video:


Double Roller Blind

Decide which way you'd like to install your curtain, inside mount or outside mount. Measure by the following instructions:



Inside Mount

■ Install within the window frame. Often used in Bay Windows, or windows with windowsill.
■ Smooth and simple outlook. Reduce the area of covering window.




Inside Mount Measurement

STEP 1Measure the in frame width
Please measure positions of left, middle, and right. Write down the minimum figures of these three, and that is the blind width.

STEP 2Measure the in frame height
Please measure positions of top, middle, and bottom. Record the maximum figures of these three, and that is the blind height.

STEP 3:  Measure the depth of window frame & the thickness of handle bar exceeds window frame.
Depth of window frame — thickness of operating bar exceeds window frame   8cm, the blinds can fit in the frame.



 Minimum size unit: 0.5cm
 The shape of window may not be vertical and level. It is suggested to measure three positions of height and width to avoid
    unseccessful installation.
 Reducing 0.5~1cm is suggested for customized width. This is to leave some space for possible alteration in installation work.
■ The covering area of drape indents from left and right side. 2cm for ballchain control/ 1.5 cm for end control. Outside mount
    installation is suggested for complete coverage.





Outside Mount

■ Install on the surface, wall, or ceiling beyond the range of frame.
■ Can cover the window completely, hide window frame, increase covering area and reduce light leak in
    from surroundings.

■ Can hide window shape and adjust visual effect of th space.



Outside Mount Measurement

STEP 1 Decide the length of blind:
Measure the in-frame width + extra width expected to cover = width needed

STEP 2 Decide the width of blind:
Measure the in-frame height + extra height expected to cover = height needed

■ Minimum size unit: 0.5cm
■ It is suggested to add more than 7~10cm all around the window frame. The actual extra covering area depends on the conditions of
   the space or visual effects requested.
■ If installed in the curtain box, reduce 0.5~1 cm on customized width is suggested to keep some space for possible alteration in
   installation work.


Reminders

■ The surroundings of window has to be completely flat and no obstables around when deciding window sizes.
■ Sizes shown on the products in the shipment are the sizes including systems and components.

Illustrations of sizes of window/ curtain box



Video instruction

How to get complete sizes on installation area of inside mount/ outside mount?
How to know inside mount/ outside mount is best for your blinds/ curtains?

>> Complete instruction




DIY illustration of Delicate Type of Double Roller Blind



Tools: A ladder, an electric drill (with 6mm tail), a hammer, electric screwdriver, a measuring tape, a level and a pencil.
Components: Self-tapping screws, normal screws, plastic nylon anchors, safety hook,and bracket.



Steps:



1. Decide the method of fitting brackets: Top-fixing or Face-fixing.




2. Mark reference holes to fix support bracket. Make sure that they are leveled.

* 3 to 4 brackets might be needed for wider requirements. The distance between these brackets should be even to avoid uneven weight.



3. Drill at the reference mark, nail plastic nylon anchors into the wall and secure the mounting brackets.




4. Snap the notch at the front of the headrail into the front side of the bracket.



5-1. Push up the headrail and evenly place.

5-2. Snap the bracket into the notch at the back of the headrail. It is securely locked after hearing the “click” sound.

* Do not press against the roll in the headrail. The roll might be damaged.

* Make sure the headrail is securely locked in order to prevent it from falling.



6. Fix ballchain onto the safety hook and straighten it. Secure safety hook on the wall with screws.

*The installation is optional, depending on your usages and housing environment of child safety.



7. Installation complete

* Notice: Keep children away from accessories, pulling cords and slats. Any installation question, please contact MSBT staff for assistance.

* Attachment: Customized Double Roller Blind Installation Instruction A4 Download/Print


Installing Double Roller Blind:
