Zaiki Roller Blinds Texture

Embroidery, embossed patterns render exquisite texture. Adding different styles to the simple outlook of roller blind.

More made to measure Roller Blinds

Insert sizes for an estimate: NTD {$ formatPrice(pre_calc_price) $} up

Width

cm

Out of range

Height

cm

Out of range

Customizable size range:
Width: {$ size_range.width.min ? size_range.width.min : '' $} {$ size_range.width.min && size_range.width.max ? ' ~ ' : '' $} {$ size_range.width.max ? size_range.width.max : '' $} cm {$ size_range.width.max ? '' : 'Above' $} |Height: {$ size_range.height.min ? size_range.height.min : '' $} {$ size_range.height.min && size_range.height.max ? ' ~ ' : '' $} {$ size_range.height.max ? size_range.height.max : '' $} cm {$ size_range.height.max ? '' : 'Above' $}

Specs

Specs

Measurement

Measurement

Installation

Installation

Case Portfolio

Case Portfolio

Specs& Systems: Roller Blind- Zaiki

Basic Specs


[Size] Including headrail hardware
Ready-made: Can be customized within 180cm(W) x 180cm(H)
Custom-made: Can be customized within 280cm(W) x 300cm(H) Fabric width
[Material] Polyester, Aluminum Alloy
[Cleaning] Non-washable on the surface, use a dry cloth, duster or a vacuum cleaner with a brush head to dust.

■ Complete installation instructions and components attached.



Sizes& Figures

Ready-made Products

Simple Type(Unhidden Roll)




Custom-made Products

1. Simple Type(Unhidden Roll)



2. Delicate Type(With metallic cover for adornment and dust-proof)


 Brackets and hardwares are included in the blind. The total thickness after installation, depending on the system sizes and directions of installation, is about 4.5cm~10cm.
 S-type headrail system is applied in custom-made products with width below 180cm; M-type is applied with width above 180cm.
 If the blind is installed in the curtain box or notch, the inner depth should be more than 8cm~12cm for smooth installation.
 The covering area indents due to parts from left and right sides. Ballchain control: 2cm/ Bottom: 1cm.



Choosing Operation


Ready-made Products

Ballchain Loop(Safety guide attached)


Custom-made Products

1. Ballchain Loop(Safety guide attached)


2. Hydraulic Spring System

3. Motorized remote control


4. Motorized simple pull
  No remote (Max W. 180cm) >> Operation Video



Color-matching Services

Custom-made products
Bracket, headrail systems, and plastic ballchain- Four colors available: White/ Beige/ Grey( Metallic silver)/ Black.
Metal ballchian is available for purchase to create your own unique personality and brilliance.



Additional Purchase Service

Ready-made Products
■ Black bracket System- with black plastic ballchain
 Metal Ballchain-Grey Nickle/Black Nickle/Satin Nickle/Old Brass/Copper, Iron nickle plated
 Tassel-With ballchain loop. Design in Europe. Decorative tassel.

Custom-made Products

 Delicate metallic cover-Four colors available: White/Beige/Grey (Metallic silver)/Black
 Metal Ballchain-Grey Nickle/Black Nickle/Satin Nickle/Old Brass/Copper, Iron nickle plated
 Tassel-With ballchain loop. Design in Europe. Decorative tassel.
 Hydraulic Spring System-Delicate type only, length of the string can be customized, Tassel- Metallic Silver enclosed
 Motorized remote control-Simple type only. Minimum width: 75cm

Operation/Cleaning

Video:



Roller Blind

Decide which way you'd like to install your curtain, inside mount or outside mount. Measure by the following instructions:



Inside Mount

■ Install within the window frame. Often used in Bay Windows, or windows with windowsill.
■ Smooth and simple outlook. Reduce the area of covering window.




Inside Mount Measurement

STEP 1Measure the in frame width
Please measure positions of left, middle, and right. Write down the minimum figures of these three, and that is the blind width.

STEP 2Measure the in frame height
Please measure positions of top, middle, and bottom. Record the maximum figures of these three, and that is the blind height.

STEP 3:  Measure the depth of window frame & the thickness of handle bar exceeds window frame.
Depth of window frame — thickness of operating bar exceeds window frame   7cm, the blinds can fit in the frame.



 Minimum size unit: 0.5cm
 The shape of window may not be vertical and level. It is suggested to measure three positions of height and width to avoid
    unseccessful installation.
 Reducing 0.5~1cm is suggested for customized width. This is to leave some space for possible alteration in installation work.
■ The covering area of drape indents from left and right side. 2cm for ballchain control/ 1 cm for end control. Outside mount
    installation is suggested for complete coverage.





Outside Mount

■ Install on the surface, wall, or ceiling beyond the range of frame.
■ Can cover the window completely, hide window frame, increase covering area and reduce light leak in
    from surroundings.

■ Can hide window shape and adjust visual effect of th space.



Outside Mount Measurement

STEP 1 Decide the length of blind:
Measure the in-frame width + extra width expected to cover = width needed

STEP 2 Decide the width of blind:
Measure the in-frame height + extra height expected to cover = height needed

■ Minimum size unit: 0.5cm
■ It is suggested to add more than 7~10cm all around the window frame. The actual extra covering area depends on the conditions of
   the space or visual effects requested.
■ If installed in the curtain box, reduce 0.5~1 cm on customized width is suggested to keep some space for possible alteration in
   installation work.


Reminders

■ The surroundings of window has to be completely flat and no obstables around when deciding window sizes.
■ Sizes shown on the products in the shipment are the sizes including systems and components.

Illustrations of sizes of window/ curtain box



Video instruction

How to get complete sizes on installation area of inside mount/ outside mount?
How to know inside mount/ outside mount is best for your blinds/ curtains?

>> Complete instruction




DIY Illustration of Customized Roller Blind


■ Tools: A ladder, an electric drill (with 6mm tail), a hammer, electric screwdriver, a measuring tape, a level and a pencil.

Components: Self-tapping screws, normal screws, plastic nylon anchors, safety hook, pin end, side cover of brackets, base cover of mounting brackets.


Steps of simple type of roller blinds:


1. Decide the method of fitting brackets: Face-fixing, Top-fixing or Side-fixing.



2.Mark reference holes to fix support bracket. Make sure that they are leveled.



3. Drill at the reference mark, nail plastic nylon anchors into the wall and secure the mounting brackets.




4. Push the bottom of the base cover into the notch of the bracket. It is securely locked when you hear “click” sound.

    *This installation is optional, depending on the space of the installation or aesthetic demands.






5-1. Make sure the end engraved with the word-“metal”  insert into the bracket, and it is securely locked after hearing “click” sound.

5-2. Place the end of the roller blind into side cover of brackets.

* The idler end (the opposite side of ball chain) is the direction of installing the end.




6. Make sure the the end of ballchain control engraved with word-“metal” is locked into the bracket. Hearing click sound means it is securely locked into the clutch.




7.  Insert the side cover of the bracket into the notch of bracket; hearing click sound means it is tightly locked into the side cover of the bracket.

**This installation is optional, depending on the space of installation site or aesthetic demands.




8. Fix ball chain on the safety hook and straighten it. Secure safety hook on the wall with screws.

**The installation is optional, depending on your habits and housing environment of child safety.




9. Installation complete

* Notice: Keep children away from accessories, pulling cords and slats. Any installation question, please contact MSBT staff for assistance.









Similar Products

Browsed Items

Warranty

  • • Unpack and check product conditions upon delivery

  • • Our on-site services or installation includes acceptance check and examination to ensure our service is well delivered.

  • • One-year warranty is granted under normal usages and for non man-made defects.

  • • When warranty period expires, maintenance or part costs will be charged after evaluation.
