Aibo Roller Blinds PVC sunscreen
Splash-resistant PVC sunscreen fabric, stiffening and durable. Reduce glare, keep ventilated and penetrant.
More made to measure Roller BlindsInsert sizes for an estimate: NTD {$ formatPrice(pre_calc_price) $} up
Width
cm
Out of range
Height
cm
Out of range
Customizable size range:
Width: {$ size_range.width.min ? size_range.width.min : '' $}
{$ size_range.width.min && size_range.width.max ? ' ~ ' : '' $}
{$ size_range.width.max ? size_range.width.max : '' $} cm
{$ size_range.width.max ? '' : 'Above' $}
｜Height: {$ size_range.height.min ? size_range.height.min : '' $}
{$ size_range.height.min && size_range.height.max ? ' ~ ' : '' $}
{$ size_range.height.max ? size_range.height.max : '' $} cm
{$ size_range.height.max ? '' : 'Above' $}
Colors:
Delete a swatch
Get a swatch
Aegean Beige(On Sale!)
Specs& Systems: Roller Blind- Aibo
[Size] includes hardware of headrail
Ready-made: Can be customized within 180cm(W) x 220cm(H) or within 90cm(W) x 250(H)
Custom-made: Can be customized within 250(W) x 300cm (H)
[Material] PVC, Polyester, Aluminum
[Cleaning] Non-washable on the surface, use a dry cloth, duster or a vacuum cleaner with a brush head to dust.
■ Complete installation instructions and components attached
Ready-made Products
Simple Type (Unhidden roll)
Custom-made Products
1. Simple Type (Unhidden Roll)
2. Delicate Type（With metallic cover for adornment and dust-proof)
■ Brackets and hardwares are included in the blind. The total thickness after installation, depending on the system sizes and directions of installation, is about 4.5cm~10cm.
■ S-type headrail system is applied in custom-made products with width below 180cm; M-type is applied with width above 180cm.
■ If the blind is installed in the curtain box or notch, the inner depth should be at least more than 8cm~12cm for smooth installation.
■ The covering area indents due to parts from left and right sides. Ballchain control: 2cm/ Bottom: 1cm.
Ready-made Products
Ballchain loop（Safety guide enclosed）
Custom-made Products
1. Ballchain loop（Safety guide enclosed）
2. Hydraulic Spring System
3. Motorized remote control
4. Motorized simple pull
No remote (Max W. 180cm) >> Operation Video
Ready-made Products
White brackets, white plastic ball chain.
Custom-made Products
Bracket, headrail systems, and plastic ballchain- Four colors available: White/ Beige/ Grey( Metallic silver)/ Black.
Metal ballchian is available for purchase to create your own unique personality and brilliance.
Ready-made Products
■ Metal Ballchain－Silver／Black Nickle／Satin Nickle／Old Brass／Copper, Iron nickle plated
■ Tassel－With ballchain loop. Design in Europe. Decorative tassel
Custom-made Products
■ Fancy metallic cover－Four colors available: White／Beige／Grey (Metallic silver)／Black
■ Metal Ballchain－Grey Nickle／Black Nickle／Satin Nickle／Old Brass／Copper, Iron nickle plated
■ Tassel－With ballchain loop. Design in Europe. Decorative tassel.
■ Hydraulic Spring System－Fancy type only, length of the string can be customized, Tassel- Metallic Silver enclosed
■ Motorized remote control－Simple type only. Minimum width: 75cm
■ Custom Printed Service－Semi-Transparant／Black-Out, show unique design or color as your wish
Video：
Roller Blind
Decide which way you'd like to install your curtain, inside mount or outside mount. Measure by the following instructions:
Inside Mount
■ Install within the window frame. Often used in Bay Windows, or windows with windowsill.
■ Smooth and simple outlook. Reduce the area of covering window.
STEP 1：Measure the in frame width
Please measure positions of left, middle, and right. Write down the minimum figures of these three, and that is the blind width.
STEP 2：Measure the in frame height
Please measure positions of top, middle, and bottom. Record the maximum figures of these three, and that is the blind height.
STEP 3: Measure the depth of window frame & the thickness of handle bar exceeds window frame.
Depth of window frame — thickness of operating bar exceeds window frame ≧ 7cm, the blinds can fit in the frame.
■ Minimum size unit: 0.5cm
■ The shape of window may not be vertical and level. It is suggested to measure three positions of height and width to avoid
unseccessful installation.
■ Reducing 0.5~1cm is suggested for customized width. This is to leave some space for possible alteration in installation work.
■ The covering area of drape indents from left and right side. 2cm for ballchain control/ 1 cm for end control. Outside mount
installation is suggested for complete coverage.
■ The surroundings of window has to be completely flat and no obstables around when deciding window sizes.
■ Sizes shown on the products in the shipment are the sizes including systems and components.
DIY Illustration of Customized Roller Blind
■ Tools: A ladder, an electric drill (with 6mm tail), a hammer, electric screwdriver, a measuring tape, a level and a pencil.
■ Components: Self-tapping screws, normal screws, plastic nylon anchors, safety hook, pin end, side cover of brackets, base cover of mounting brackets.
Steps of simple type of roller blinds:
1. Decide the method of fitting brackets: Face-fixing, Top-fixing or Side-fixing.
2.Mark reference holes to fix support bracket. Make sure that they are leveled.
3. Drill at the reference mark, nail plastic nylon anchors into the wall and secure the mounting brackets.
4. Push the bottom of the base cover into the notch of the bracket. It is securely locked when you hear “click” sound.
*This installation is optional, depending on the space of the installation or aesthetic demands.
5-1. Make sure the end engraved with the word-“metal” insert into the bracket, and it is securely locked after hearing “click” sound.
5-2. Place the end of the roller blind into side cover of brackets.
* The idler end (the opposite side of ball chain) is the direction of installing the end.
6. Make sure the the end of ballchain control engraved with word-“metal” is locked into the bracket. Hearing click sound means it is securely locked into the clutch.
7. Insert the side cover of the bracket into the notch of bracket; hearing click sound means it is tightly locked into the side cover of the bracket.
**This installation is optional, depending on the space of installation site or aesthetic demands.
8. Fix ball chain on the safety hook and straighten it. Secure safety hook on the wall with screws.
**The installation is optional, depending on your habits and housing environment of child safety.
9. Installation complete
* Notice: Keep children away from accessories, pulling cords and slats. Any installation question, please contact MSBT staff for assistance.
Warranty
• Unpack and check product conditions upon delivery
• Our on-site services or installation includes acceptance check and examination to ensure our service is well delivered.
• One-year warranty is granted under normal usages and for non man-made defects.
• When warranty period expires, maintenance or part costs will be charged after evaluation.
